Multitube MRDDP
MRDDP
Multitube
MRDDP
Multitube

Multi-tube design heat exchanger, with removable tube bundle, double tubesheets, pitched installation for self-draining, hygienic/sanitary design according to 3A standards, with corrugated or plain tubes, recommended for processing low and medium viscosity fluids, homogeneous fluids or fluids with small particles in suspension.

Temperature conditions 180ºC and 25 bar pressure (others on request).

Manufactured in austenitic stainless steel, superaustenitic, duplex and titanium.

DEU
DEU
SHELL AND TUBES
DEU
SHELL AND TUBES

Shell and tubes heat exchanger according to TEMA DEU standards. Specially recommended for very high pressure conditions (up to 1000 bar(g) ); the tube bundle incorporates corrugated or plain tubes.

According to the design temperature and pressure conditions and fluids process, materials are selected from all metals available like: austenitic stainless steels, duplex, high temperature resistance steels, superaustenitic, exotic alloys (Inconel, Incolloy, Monel, Hastelloy), titanium alloys (grade 1, 2, 3, 4, 7 and 11), coppernickel Cu/Ni 90/10 and 70/30, Admiralty brass, copper and carbon steel.

Multitube M
M
Multitube
M
Multitube

Multi-tube design heat exchanger, with welded or removable tube bundle, hygienic/sanitary designed according to 3A standards, with corrugated or plain tubes, recommended for processing low and medium viscosity fluids, homogeneous fluids or fluids with small particles in suspension.

Temperature conditions 180ºC and 25 bar pressure (others on request).

Manufactured in autenitic stainless steel, superaustenitic, duplex and titanium.

NEN
NEN
SHELL AND TUBES
NEN
SHELL AND TUBES

Shell and tubes heat exchanger according to TEMA NEN standard. This design with removable back end flanges allows tube side inspection without dismantling the heat exchanger from the pipeline.

According to the design temperature and pressure conditions and fluids process, materials are selected from all metals available like: austenitic stainless steels, duplex, high temperature resistance steels, superaustenitic, exotic alloys (Inconel, Incolloy, Monel, Hastelloy), titanium alloys (grade 1, 2, 3, 4, 7 and 11), coppernickel Cu/Ni 90/10 and 70/30, Admiralty brass, copper and carbon steel.

Pharmagrade
PH
Pharmagrade
PH
Pharmagrade

Multitube heat exchanger designed according to ASME BPE standards, with double tubesheets to avoid cross contamination, with welded or removable tube bundle, welded or seamless corrugated or smooth tubes, electropolished or mechanically polished (tube side surface roughness Ra<= 0.25 / 0.4 / 0.5 microns) and self-draining design.

Temperature conditions 180ºC and 25 bar pressure (others on request).

Manufactured in austenitic stainless steel (other materials on request).

Monotube S
S
Monotube
S
Monotube

Monotube design heat exchanger, with fully welded design or with removable inner tube. Tubes can be corrugated, dimpled or plain.

Recommended for processing sludge, slurries and fluids in general with solids in suspension of any size.

Standard range design conditions: temperature 350ºC and pressure 25 bar(g) (others on request). Manufactured in stainless steel, Duplex and Titanium.

Monotube DD
DD
Monotube
DD
Monotube

Monotube heat exchanger for hygienic/sanitary duties according to 3A standards, to process fluids with solids in suspension like fibers, cells or particulates (diced products).

Temperature conditions 180ºC and 25 bar(g) pressure (others on request).

Manufactured in austenitic stainless steel, superaustenitic, duplex and titanium.

I-Series
I-SERIES
SHELL AND TUBES
I-SERIES
SHELL AND TUBES

Shell and tubes heat exchanger with fixed tubesheets with corrugated tube bundle (other tube profiles available).

Standard range temperature conditions 350ºC and 200 bar(g) pressure (others upon request).

Manufactured in stainless steel, Duplex, Titanium, special alloys (Hastelloy, Incolloy, Inconel, etc), carbon steel and any other metal (except Tantalum).

Shell and tube heat exchanger BEW
BEW
Shell and tubes
BEW
Shell and tubes

Shell and tubes heat exchanger according to TEMA BEW standard, with floating tubesheets, B head type, removable tube bundle, with corrugated or plain tubes.

According to the design temperature and pressure conditions and fluids process, materials are selected from all metals available like: austenitic stainless steels, duplex, high temperature resistance steels, superaustenitic, exotic alloys (Inconel, Incolloy, Monel, Hastelloy), titanium alloys (grade 1, 2, 3, 4, 7 and 11), coppernickel Cu/Ni 90/10 and 70/30, Admiralty brass, copper and carbon steel.

Reboiler BKU
BKU
SHELL AND TUBES
BKU
SHELL AND TUBES

Shell and tubes heat exchanger designed according to TEMA BKU standard usually utilized as reboiler. The tubes bundle includes corrugated U-tubes, and also other tube profiles and plain tubes.

According to the design temperature and pressure conditions and fluids process, materials are selected from all metals available like: austenitic stainless steels, duplex, high temperature resistance steels, superaustenitic, exotic alloys (Inconel, Incolloy, Monel, Hastelloy), titanium alloys (grade 1, 2, 3, 4, 7 and 11), coppernickel Cu/Ni 90/10 and 70/30, Admiralty brass, copper and carbon steel.

Multicanal
T3/T4
Multicanal
T3/T4
Multicanal

The heat exchanger is formed by 3 or 4 concentric corrugated tubes. Specially recommended for processing concentrates and fluids of high viscosity and low acidity, homogeneus or with small particles in suspension. Hygienic/sanitary designed according to 3A standards.

Temperature conditions 180ºC and 25 bar(g) pressure (others on request).

Manufactured in austenitic stainless steel, superaustenitic, duplex and titanium.

Processing plant
PLANT
Processing plant
PLANT
Processing plant

Complete pasteurization or sterilization plants for the food industry, dairy industry, etc., with XLG® heat exchangers as well as high quality equipment (pumps, valves, flowmeters, homogenizers, etc.), tanks, electrical cabinet and control system, all on a self-supporting structure.

Shell and tube heat exchanger BEU
BEU
Shell and tubes
BEU
Shell and tubes

Shell and tubes heat exchanger according to TEMA BEU standard. Tube bundle incorporates corrugated U tubes, another tube profiles or plain tubes are available depending on the fluid characteristics.

According to the design temperature and pressure conditions and fluids process, materials are selected from all metals available like: austenitic stainless steels, duplex, high temperature resistance steels, superaustenitic, exotic alloys (Inconel, Incolloy, Monel, Hastelloy), titanium alloys (grade 1, 2, 3, 4, 7 and 11), coppernickel Cu/Ni 90/10 and 70/30, Admiralty brass, copper and carbon steel.

DOUBLE WALL
DOUBLE WALL
SHELL AND TUBES
DOUBLE WALL
SHELL AND TUBES

This heat exchanger includes double concentric tubes instead of a single one (like standard shell and tubes) so there are two walls separating the product and service media. This way a super secure system is created to prevent cross contamination between both fluids. A leak detection system monitors any pressure change in the separation chamber warning any tube or seam crack. According to the design temperature and pressure conditions and fluids process, materials can be: austenitic stainless steels, duplex, high temperature resistance steels, superaustenitic, exotic alloys (Inconel, Incolloy, Monel, Hastelloy), titanium , coppernickel and carbon steel.

SDR
SDR
MONOTUBE
SDR
MONOTUBE

Monotube design heat exchanger specially designed for heat recovery applications when fluids contain solids in suspension (sludge, slurries, fibres).

Tubes can be corrugated, dimpled or plain.

Standard range design conditions: temperature 350ºC and pressure 25 bar(g) (others on request). Manufactured in stainless steel, Duplex and Titanium.

SX
SX
MONOTUBE
SX
MONOTUBE

Monotube heat exchanger that incorporates squared shells and round inner tubes. This design permits a very compact solution with a minimum footprint. Inner tube can be fixed or removable, usually corrugated or plain.

Recommended for processing sludge, slurries and fluids in general with solids in suspension of any size.

Standard range design conditions: temperature 100ºC and pressure 5 bar(g) (others on request). Manufactured in stainless steel.

HAIRPIN MULTITUBE
HS
HAIRPIN MULTITUBE
HS
HAIRPIN MULTITUBE

This heat exchanger includes a tube bundle with U-tubes inside a U-shaped shell. Tubes corrugated or plain. Flow is pure countercurrent and enables very high temperatures crossing between tube side and shell side fluids.

According to the design temperature and pressure conditions and fluids process, materials are selected from all metals available like: austenitic stainless steels, duplex, high temperature resistance steels, superaustenitic, exotic alloys (Inconel, Incolloy, Monel, Hastelloy), titanium alloys (grade 1, 2, 3, 4, 7 and 11), coppernickel Cu/Ni 90/10 and 70/30, Admiralty brass, copper and carbon steel.

HAIRPIN MONOTUBE
HI
HAIRPIN MONOTUBE
HI
HAIRPIN MONOTUBE

This heat exchanger includes a U-tube inside a U-shaped shell. Inner tube corrugated or plain. Flow is pure countercurrent and enables very high temperatures crossing between tube side and shell side fluids.

According to the design temperature and pressure conditions and fluids process, materials are selected from all metals available like: austenitic stainless steels, duplex, high temperature resistance steels, superaustenitic, exotic alloys (Inconel, Incolloy, Monel, Hastelloy), titanium alloys (grade 1, 2, 3, 4, 7 and 11), coppernickel Cu/Ni 90/10 and 70/30, Admiralty brass, copper and carbon steel.

COIL MONOTUBE
CM
COIL MONOTUBE
CM
COIL MONOTUBE

Formed by two concentric tubes that are coiled to become a very compact and self-drainable heat exchanger. It has no interconnections and gaskets being ideal for high pressure applications. The inner tube can be corrugated or dimpled.

Design conditions: Temperature max 180ºC, pressure max 25 bar(g) (higher conditions on request).

Materials of construction: austenitic stainless steels, duplex, high temperature resistance steels, superaustenitic, exotic alloys (Inconel, Incolloy, Monel, Hastelloy), and titanium alloys (grade 1, 2, 3, 4, 7 and 11).

COIL MULTITUBE
CC
COIL CALANDRIA
CC
COIL CALANDRIA

A coiled inner tube is contained inside a calandria. The product flows inside the tube while the service media runs outside.

It has no interconnections and gaskets being ideal for high pressure applications. The inner tube can be corrugated, dimpled or plain.

Design conditions: Temperature max 180ºC, pressure max 25 bar(g) (higher conditions on request).

Materials of construction: austenitic stainless steels, duplex, high temperature resistance steels, superaustenitic, exotic alloys (Inconel, Incolloy, Monel, Hastelloy), and titanium alloys (grade 1, 2, 3, 4, 7 and 11).

Superficie Rascada Boxer
Boxer
Scraped surface
Boxer
Scraped surface

Scraped surface heat exchanger with multi-tube design, recommended for high viscosity fluids and/or high fouling applications.

Heating, cooling, condensation and evaporation processes.

Temperature conditions 250ºC and 25 pressure (others on request). Manufactured in stainless steel and Duplex.
